Description
[ HD 1080P resolution ] - 1920×1080p resolution provide more clarity. The living stream can be accessed via iOS / Android mobile Phone, Windows PC. Max 4 devices can view at the same time. One device can add Max 64 cameras. Support 2.4Ghz wifi (does not support 5Ghz wifi currently).
[ 108° Panoramic Camera ] - 107.7°（diagonal）wide viewing angle lens ,give your house 180° surveillance protection.
[ Night vision & Motion detection ] - VStarcam camera built-in 6pcs IR LED infrared vision light, the night vision up to 10m. When the camera is at defense the motion detection alarm is available, Alert will be sent by email / app. You can use it as baby / elder / nanny / pet monitor. Keep the place or people you love safe 24/7.
[ Two- way audio ] - Built-in speaker and microphone, you can see, hear and speak to whoever is standing in front of VStarcam home security camera directly,such as baby,pet,elderly,and thief.
[ Cloud Service & Max 128G TF card storage ] - Support max 128G TF card(card not included) storage. VStarcam Cloud Service is also available. You can live-stream your footage or play back based on your preference. Easy operation with in tuitive interface. VStarcam provide 1 year warranty.
[ Support Echo Show ]
Specifications
| System |
Operation system |
Embedded Linux OS |
| Online visitor |
Support 4 visitors at the same time |
| Image Capture |
Image sensor |
1/2.7inch 1080p Progressive Scan CMOS |
| Minimum Illumination |
0.3~0.5Lux(color mode),0Lux(B&W mode) |
| Lens |
4mm@F2.1 |
| View Angle |
107.7˚Diagonal |
| Nightvision |
Dual Filter,IR-Cut，6pcs 850nm SMD IR LED， IR irradiation distance:5~10m |
| Video |
Encode format |
H.264 main profile@levels:4.0/Motion-JPEG |
| Three Stream |
Main Stream:1080p(1920X1080)@15fps Sub Stream:360p(640X360)@15fps Third Stream:180p(320X180)@10fps |
| Bit Rate |
128～4096kbps |
| Maximum frame rate |
15fps |
| Image adjustment |
Contrast、Brightness、Saturation、Hue |
| Audio |
Input |
Built-in -48dB Microphone |
| Output |
Built-in 8Ω1W speaker |
| Sampling frequency |
8KHz |
| Sampling Bit wide |
16bit |
| Encode format/Bit rate |
ADPCM/32kbps |
| Network |
Ethernet |
10Base-T / 100Base-TX, RJ45 connector |
| Protocols |
TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc |
| Wireless LAN |
IEEE802.11b/g/n |
| Wireless LAN Frequency |
2.4~ 2.4835GHz |
| Wireless LAN security |
64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption |
| Memory |
Socket |
TF Push-push socket,Maximum support 128GB; Cloud Storage |
| Alarm |
Alarm Trigger |
Motion detection |
| Physical Environmental |
Rated voltage |
DC5V±5% |
| Power consumption |
Typical:3.5W(IR LED turn on) |
| Operating condition |
Temperature:-10～50℃,humidity:＜90% |
| Weight |
Gross：262.5g Net:88g (Note: in kind prevail) |
| Package size |
148*126*90mm(L×W×H) |
| Product size |
125X71X85mm (L×W×H) |
