| System |
Operation system |
Embedded Linux OS |
| Online visitor |
Support 4 visitors at the same time |
| Image Capture |
Image sensor |
1/2.9inch 1080p Progressive Scan CMOS |
| Minimum Illumination |
0.3~0.5Lux(Color mode),0.1Lux(B&W Mode) |
| Lens |
6.0mm@F2.7 |
| View Angle |
58°(diagonal) |
| Night vision |
Dual Filter,IR-Cut,2pcs 850nm SMD IR LED IR irradiation distance:5~10m |
| Video |
Encode format |
H.264+/H.264 main profile/Motion-JPEG/JPEG |
| Streams |
Main stream:1080p(1920×1080)@30fps/1296p(2304×1296)@30fps Substream:360p(640×360)@15fps |
| Bit Rate/Max Fps |
128~4096kbps/30pfs |
| Image adjustment |
Brightness and contrast can be adjusted |
| Audio |
Input |
Built-in -38 dB microphone |
| Output |
Built-in speaker(8Ω1W) |
| Sampling frequency / width |
8KHz/16bit |
| Compression standard |
ADPCM/32kbps |
| Network |
Ethernet |
10Base-T / 100Base-TX, RJ45 connector |
| Protocols |
TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc |
| Wireless LAN |
IEEE802.11b/g/n |
| Wireless LAN Frequency |
2.4~ 2.4835GHz |
| Wireless LAN security |
64/128-bit WEP/WPA-PSK /WPA2-PSK data encryption |
| Pan-tilt |
Pan-tilt |
Pan:350°,Tilt:88° |
| Preset position |
PC APP:support 16 positions, phone APP:support 5 positions |
| Memory |
Socket |
TF Push-push socket,Maximum support 256GB; cloud storage;NVR;NAS |
| Alarm |
Alarm Trigger |
Motion detection, Humanoid detection, Humanoid tracking, Crying detection, Face recognition, Smoke detector alarm detection, absence monitoring |
| Physical Environmental |
Rated voltage |
DC 5V±5% |
| Power consumption |
Related power:2.5W(IR LED on), Maximum Power: 4.45W(Pan&Tilt on) |
| Operating condition |
Temperature:-10~50℃,humidity:<90% |
| Weight |
Gross:TBD g(Note: in kind prevail) |
| Package size |
TBD mm(L×W×H) |
